Stainless Steel Heating Plate

Hangzhou Qiwei Instrument Co., Ltd. is one of the leading manufacturers and suppliers of stainless steel heating plate in China. With a professional production team, we are able to meet the needs of the majority of our customers. Welcome to wholesale bulk stainless steel heating plate in stock here from our factory. We also accept customized orders.





The ZNDrb40 stainless metal heating plate is listed with a most temperature of 400°C. Before deciding on a mannequin for a precise process, verify the accredited working temperature for the supposed load, vessel, and floor material.

Heating uniformity describes how evenly temperature is allotted throughout the working floor beneath described take a look at conditions. It is exclusive from the controller's temperature putting or the most temperature that the plate can reach.

For purposes that require repeatable heating, request the manufacturer's temperature distribution data, including:

- Tested setpoint temperatures

- Measurement positions throughout the heating surface

- Warm-up and stabilization time earlier than measurement

- Test conditions, such as whether or not the plate is unloaded or carrying a described load

- Maximum temperature distinction throughout the measured surface

A temperature distribution curve or size desk can assist shoppers consider whether or not the heating plate meets their system requirements. Actual overall performance must be assessed the use of the manufacturer's established check statistics alternatively than an assumed uniformity value.





The stainless metal heating plate can be used for appropriate laboratory sample-heating, drying, and temperature-related procedures. Its working vicinity and most rated temperature have to be matched to the vessels, pattern quantities, and heating prerequisites required via every application.

For pattern digestion workflows, the heating plate have to solely be chosen after confirming that the uncovered surface, pattern vessels, and any add-ons are well matched with the reagents and running conditions. Strong acids, targeted chemicals, and accelerated temperatures might also require specialised substances or committed corrosion-resistant equipment.

Before use, evaluation the chemical compatibility requirements, vessel stability, authorised load, air flow arrangements, and laboratory protection procedures. Do no longer region corrosive beverages without delay on the heating floor except the producer explicitly confirms that the configuration is suitable.

For application-specific selection, please supply the pattern type, reagent composition, goal temperature, vessel dimensions, and required heating area. Our crew can evaluate the on hand specs and advocate whether or not the preferred mannequin or a exceptional configuration ought to be considered.





When the electric heating plate is in operation, it should be supervised by a dedicated person. Do not touch the surface of the workbench with your hands to avoid burns. After the work is completed, cut off the power supply.





1. Daily maintenance includes cleaning and maintenance, temperature control system inspection, electrical part maintenance, heating plate inspection and post-use inspection.

2. Cleaning and maintenance requires regular cleaning of the surface of the electric heating plate, removal of dust and liquid splashes, and avoidance of the use of corrosive cleaners, while cleaning the temperature control panel.

3. The temperature control system needs to calibrate the temperature controller to ensure that the displayed temperature is consistent with the actual temperature, and check the temperature setting and temperature sensor.

4. Electrical part maintenance should check the power cord, plug, and regularly power off.

5. The heating plate inspection needs to avoid overload, check whether there are cracks in the heating area, and prevent high-temperature items from contacting.

6. Check after use should pay attention to heat dissipation, check bad contact, and keep dry.





1. What is the most temperature of the ZNDrb40 heating plate?

The ZNDrb40 stainless metal heating plate is listed with a most temperature of 400°C. The genuine working suitability relies upon on the vessel, load, floor material, and procedure conditions. Please verify the relevant running limits earlier than the use of the plate for a unique procedure.



2. What is the heating floor size?

The listed heating place of the ZNDrb40 is four hundred × 280 mm. Its listed typical dimensions are four hundred × 280 × 210 mm. If your utility requires a exclusive working area, contact us to take a look at whether or not a customized configuration is available.



3. Is the heating floor made of 304 or 316L stainless steel?

The stainless metal grade ought to be validated from the manufacturer's cloth specification. Please contact our crew to affirm the grade used for the heating floor and whether or not any extra floor cure or coating is applied.



4. Is this warm plate appropriate for acid digestion?

Suitability relies upon on the reagents, concentrations, running temperature, publicity time, and uncovered floor material. Do now not count on that a stainless metal heating floor is well matched with all digestion acids. Please supply your chemical and manner necessities so that cloth compatibility can be reviewed earlier than purchase.



5. Does the heating plate grant uniform floor temperature?

The current product specs listing a most temperature however do no longer supply a special temperature distribution curve. If your technique requires regular heating throughout the working area, request the manufacturer's temperature uniformity data, together with the check temperature, dimension positions, stabilization time, and load conditions.



6. What is the most load capacity?

The most authorized load must be demonstrated via the manufacturer. It ought to now not be inferred from the heating floor measurement or panel thickness. When asking for a quotation, grant the approximate mixed weight and footprint of your vessels, samples, and fixtures.



7. Can I request a custom-size stainless metal heating plate?

Please contact our crew with your required heating area, common dimensions, running temperature, load requirements, floor material, and meant application. We can evaluate the necessities and affirm whether or not a custom-size configuration is available.



8. What data ought to I furnish for a bulk quotation?

Please share your required quantity, destination country, goal running temperature, heating surface dimensions, load requirements, chemical publicity conditions, and any material or surface-finish requirements. These small print assist our group overview the technical necessities and put together a extra applicable quotation.
