Hangzhou Qiwei Instrument Co., Ltd. is one of the leading manufacturers and suppliers of mini digital magnetic stirrer in China. With a professional production team, we are able to meet the needs of the majority of our customers. Welcome to wholesale bulk mini digital magnetic stirrer in stock here from our factory. We also accept customized orders.
The QiweiLab compact digital magnetic stirrer is developed for liquid mixing applications where space-saving layout and simple operation are priorities. It has a 130 × 130 mm working plate, while the overall unit dimension is 150 × 200 × 55 mm. This series fits well on lab countertops, teaching labs, sample preparation stations and suitable field test scenarios.
Available models deliver stirring speeds from 0 to 1800 rpm, with a working mixing volume of 10–2000 mL. The practical stirring outcome is affected by liquid characteristics, container shape, stir bar dimensions and magnetic coupling status. When running titration training and other small-volume experiments, operators need to select matched vessels and stir bars to maintain stable mixing and avoid excessive splashing or over-vortexing.
The sequence consists of fashions with distinct timing and charging configurations. Before ordering, verify the strength supply, charging availability, timing function, and add-ons for the precise model.
Contact QiweiLab to request the present day technical specifications, examine mannequin configurations, and talk about bulk buying requirements.
product key technologies
Introduction & Principle
The compact digital magnetic stirrer is a fundamental benchtop device designed for small-volume liquid blending. It is primarily applied to agitate low-viscosity fluids as well as solid-liquid suspensions.
It operates based on the magnetic rule that unlike magnetic poles attract while like poles repel. A rotating magnetic field drives the magnetic stir bar inside the vessel to spin, so as to homogenize the contents.
Advantage
1. Compact in appearance with straightforward, user-friendly operation.
2. Carbon-brushless motor design for extended service life.
3. Continuously variable speed control with a broad speed adjustment range.
4. Powerful magnetic force, effectively preventing stir bar jumping.
5. Portable form factor to accommodate diverse experimental requirements.
Working Surface, Mixing Capacity and Speed Selection
This micro digital magnetic stirrer is engineered for small-scale liquid mixing in laboratory settings. It supports mixing volumes ranging from 10 mL up to 2000 mL, covering most common sample preparation workflows. Featuring a 130 × 130 mm working plate, it provides a compact platform to hold compatible lab glassware.
Users can modify stirring conditions to suit various liquids and experimental protocols thanks to the adjustable speed range of 0–1800 rpm. Start at a low speed and increase it gradually until the desired mixing effect is obtained for improved mixing stability.
Take into account the following aspects while choosing a small magnetic stirrer:
Working surface: Verify that the 130 x 130 mm working area can accommodate the vessel base.
Sample volume: Choose a model with a reported capacity range of 10–2000 ml based on the actual liquid volume.
Stirring speed: Depending on the size of the vessel, the stir bar, and the viscosity of the liquid, select an appropriate speed.
Stir bar compatibility: Use a magnetic stir bar appropriate for the vessel and sample volume.
Operating stability: Steer clear of abrupt speed increases that could throw off the stir bar's synchronization.
Application
This compact digital magnetic stirrer fits routine lab workflows for educational institutions, analytical testing and quality control departments, benefiting from its space-saving structure and capacity for small-volume blending.
1. Biopharmaceutical and life science sample preparation
This mini magnetic stirrer works well for blending lab reagents, dissolving solutes and making small-quantity buffer solutions in biotechnology research labs. Its small footprint suits workstations running several sample-prep operations at the same time. Operators can set stirring parameters matched to sample properties and experimental schemes when handling sensitive biological specimens.
2. Chemical preparation and titration work
Magnetic agitation supports sample makeup and calibration work during chemical analysis. Its adjustable speed range allows users to set proper stirring speeds to fit different laboratory test procedures.
3. University teaching laboratories
Its slim form is ideal for teaching labs, where students prepare basic solutions, formulate reagents and carry out introductory chemistry experiments. The small footprint also makes it easy to place multiple units on shared lab bench space.
4. Routine analysis and quality inspection
QC laboratories can adopt this mini stirrer for small-batch sample preparation, solution homogenization and regular analytical tests. Model selection should be based on target operating parameters and sample volumes.
Note: Standard mini magnetic stirrers do not come with built-in heating by default. If heating is required for your tests, please select a heated magnetic stirrer instead.
Panel Protection and Routine Cleaning
When carrying out titration training and mixed-sample preparation tasks, liquid may accidentally splash during sample transfer, stirring, or handling near the equipment. When selecting a compact digital magnetic stirrer for such work, users should take into account the layout of the control panel, surface cleaning protocols, and guidelines issued by the manufacturer.
Prior to placing an order, check if the selected unit features a splash-proof control panel, protective cover or sealing construction, together with an official IP protection grade. These technical parameters apply to the complete device and cannot be judged merely based on its outer look.
To clean the equipment after use, power it down and cut off the power supply following the manufacturer's guidance. Wipe away spilled liquid promptly using approved cleaning methods, and make sure liquids cannot seep into control keys, display gaps, ports or ventilation openings.
Avoid washing the unit under running water or submerging it, unless the manufacturer has clearly stated that this operation is permitted. If your work often involves splashing liquids, wet sample preprocessing, or operation beside sinks, ask for the safety specifications of the specific model before purchase.
For labs with defined sanitation standards or special environmental demands, share details about the expected exposure conditions. Our team can then help confirm which configuration is suitable.
Technical Parameter
|
Model |
M-CL |
MC-CL |
M-SCL |
MC-SCL |
M-SCL-T |
MC-SCL-T |
|
Timing Function |
No |
0-9999 minutes |
||||
|
Charging Function |
No |
Yes |
No |
Yes |
No |
Yes |
|
Speed Range |
0-1800 rpm |
|||||
|
Mixing Capacity |
10-2000 ml |
|||||
|
Workbench Size |
130×130 mm |
|||||
|
Power |
5W |
|||||
|
Power Supply |
12V |
|||||
|
Size |
150×200×55 mm |
|||||
|
Weight |
0.8 kg |
|||||
Selection of Conventional Magnetic Stirrer Rotor
Place the vessel holding the liquid sample on the base of the magnetic stirrer. Once the unit is powered on, a rotating magnetic field forms above the base. This field spins the stir bar inside the vessel, creating a liquid vortex for mixing. Accordingly, selecting a stirrer with sufficient magnetic strength is essential to obtain satisfactory stirring performance.
FAQ
1. What is the mixing potential of the mini digital magnetic stirrer?
The listed mixing capability of the QiweiLab mini digital magnetic stirrer sequence is 10–2000 mL. Actual overall performance relies upon on the liquid properties, vessel dimensions, stir bar size, and magnetic coupling conditions. For purposes close to the decrease stop of this range, affirm the minimal realistic working quantity with the supposed vessel and stir bar.
2. What is the workbench size?
The listed workbench measurement is 130 × 130 mm, whilst the usual instrument measurement is 150 × 200 × 55 mm. Check the base dimensions of your vessel and go away adequate area round the instrument for protected operation and get entry to to the controls.
3. What is the velocity range?
The on hand mini digital magnetic stirrer fashions are listed with a velocity vary of 0–1800 rpm. The splendid velocity relies upon on the pattern volume, viscosity, vessel geometry, and stir bar. Start at a low velocity and extend regularly to decrease splashing or loss of magnetic coupling.
4. Can this mini magnetic stirrer be used for titration sample preparation?
It is suitable for solution mixing during titration preparation, subject to your sample volume, container type and mixing requirements. While this device provides magnetic stirring function, it cannot take the place of dedicated titration measuring equipment. Please verify that the selected model meets the mixing performance requirements of your experimental protocol.
5. Can the mini digital magnetic stirrer be used for area testing?
The compact dimension and listed weight of 0.8 kg can be useful for shifting the instrument between appropriate work areas. However, discipline use relies upon on the handy strength supply and the running environment. Confirm whether or not the chosen mannequin helps charging or battery operation earlier than buying it for cell use.
6. Which fashions aid charging and timing functions?
The contemporary product specs listing charging features for MC-CL, MC-SCL, and MC-SCL-T. Timing features from 0-9999 minutes are listed for M-SCL-T and MC-SCL-T. Please verify the today's mannequin configuration and electricity necessities earlier than ordering.
7. Is the mini digital magnetic stirrer water-resistant or splash-resistant?
The posted product statistics does now not really specify an IP rating. Do now not anticipate the instrument is water-resistant or appropriate for washdown. If your software includes common splashes or operation close to moist work areas, request affirmation of the panel safety graph and the examined safety ranking for the chosen model.
8. What is blanketed in the preferred package?
Package contents must be verified for the chosen mannequin and order configuration. Please test whether or not the package deal consists of a like minded strength adapter or cable, magnetic stir bar, charging accessories, person manual, and different required items. Request a written packing listing earlier than putting a bulk order.
9. Can I order a couple of devices for laboratory or instructional use?
Yes. For bulk purchasing, supply your desired model, quantity, vacation spot country, and application. If you want a precise charging configuration, timing function, accent set, or custom-made packaging, consist of these important points in your inquiry so that availability can be confirmed.
10. How can I attain the technical datasheet?
Contact QiweiLab with the mannequin you are involved in and your commercial enterprise contact important points to request the ultra-modern technical datasheet. If you have a unique minimal pattern volume, required speed, discipline electricity requirement, or environmental safety requirement, encompass it in your request so that the applicable specs can be reviewed.
